Variform T3 Trivent High Performance Soffit, 12' Panels, Hidden Vent, 2 Colors
Regular price $32.25Orders start at $399 — combine any items to reach the minimum. Learn more
Variform T3 Trivent High Performance Soffit, 12' Panels, Hidden Vent, 2 Colors
Variform's T3 Trivent High Performance Soffit delivers the highest ventilation performance in the Variform vinyl soffit line with a hidden vent that allows 50% more airflow. Choose Dover White or Twilight Shadow in 12 ft. solid or hidden-vent panels. Its 5/8 in. projection and soft matte finish look sharp on porches, eaves and overhangs. One piece or carton per order unit.
Key Features:
- 50% more airflow: The Trivent X-Tra hidden vent design allows 50% more airflow, reducing utility bills and preventing mold and mildew damage.
- 5/8 in. projection: Enhanced 5/8 in. panel projection replicates the shadow lines of real wood siding.
- Matte finish: A sleek, soft matte finish with a deep shadow line delivers exceptional curb appeal.
- Dirt-shedding vents: The unique vent design doesn't trap dirt, minimizing cleaning over the years.
- Extra thick: Durable, extra-thick panels resist dents from everyday life.
- Recyclable: Made from a sustainable, recyclable formulation.
Specifications Table:
| Specification | Details |
|---|---|
| Brand | Variform |
| Sell unit | 1 panel or carton depending on variant; 12 ft. Solid or Hidden vent panels |
| Product line | T3 Trivent High Performance Soffit |
| Available colors | Dover White, Twilight Shadow |
| Available sizes | 12 ft. Solid and 12 ft. Hidden vent panels |
| Material | Vinyl |
| Profile | Triple 3 in. (T3) with 5/8 in. projection |
| Dimensions | 12 ft. length |
| Ventilation | Hidden Vent allows 50% more airflow than standard vented soffit |
| Finish / texture | Soft matte with deep shadow line |
| Intended use | Porches, covered decks, eaves, overhangs and porte-cocheres |
Coverage & How Much You Need:
Each 12 ft. panel covers the full triple 3 in. panel width, about 9 in. per course. Measure soffit or ceiling area in square feet and add roughly 5-10% for cuts and F-channel laps.
Fit and Compatibility:
Installs with Variform F-channel, J-channel and fascia trim (sold separately). Available in Solid (non-vented) and Hidden Vent versions, so mix the two to place airflow exactly where the attic design requires it.
Frequently Asked Questions (FAQ):
Q: What is included?
A: One 12 ft. T3 Trivent panel per piece, in Dover White Solid, Dover White Hidden vent, or Twilight Shadow Hidden vent depending on the variant ordered.
Q: How much more airflow does it provide?
A: The Trivent X-Tra hidden vent allows 50% more airflow than the line's standard vented soffit.
Q: Where should I use the solid version?
A: Use solid panels for porch ceilings and accent areas, and hidden-vent panels along eaves where attic intake airflow is needed.
Q: Does the vent clog with dirt?
A: No; the unique vent design doesn't trap dirt, which minimizes cleaning and keeps the surface attractive.
Q: What trim do I need?
A: F-channel or J-channel receivers and fascia trim, sold separately, complete a standard installation.
Expert Verdict — Reviewed by the SuperArbor Pro Desk
Trivent is the premium choice when intake ventilation area matters: the hidden vent's 50% airflow gain can shorten the required run of vented soffit on tight eaves. The 5/8 in. projection reads like wood on porch ceilings and porte-cocheres, so many installers run hidden-vent panels on eaves and solid panels on covered living spaces. Twilight Shadow pairs well with dark gutters and modern trim palettes.
Follow the manufacturer's nailing and expansion-gap instructions and confirm attic ventilation code requirements before choosing solid versus vented panels.
Order Variform T3 Trivent High Performance Soffit for maximum hidden airflow and premium curb appeal.
