QO 100 Amp 12-Space 12-Circuit Indoor Main Breaker Load Center with Cover

$0.00

/
Shipping calculated at checkout.
The Square D QO 100 Amp 12-Space 12-Circuit Convertible Main Breaker Indoor Load Center is UL listed for residential, commercial and industrial power distribution. This load center is built with a shielded, copper bus bar that is plated for reliability. QO load centers are tested and listed only for QO circuit breakers. QO load centers are the "World's Finest" designed with industry leading features for flexible application. QO load centers include features engineered for fast installation and wire savings.
  • California residents
  • Includes a combination flush/surface indoor cover, PK9GTA equipment ground bar kit, and factory-installed QOM100VH main breaker
  • Accommodates plug-on secondary surge arrestor (sold separately)
  • Overhead/underground feed simply by rotating the device before installing
  • Single phase
  • Rated 120/240 VAC and 22,000 AIR short circuit current rating
  • Automatic flush adjusting cover requires less time to complete the job
  • Designed with straight-in mains to save expensive cable and time
  • Split branch neutral with terminal screws backed out offering with up to 50% more terminals than UL requires increases wiring flexibility saving installation time and simplifies wiring
  • Thermoplastic interior is among the most rugged in the industry
  • Slot/square drive screws let you use either standard flat blade screwdriver or square-head driver for positive drive and proper torque
  • Convertible mains allow you to meet changing job site requirements by field converting main breaker load centers to main lugs and vice versa
  • For protection from damage or theft on the job site, interiors can be easily removed with a single captive screw
  • 3 ground bar mounting locations (left, right and end) let you pick the easiest spot to wire
  • Made in the USA


Features
Item Weight 16.13
Maximum Amperage (amps) 100
Load Center Type Main Breaker
Indoor/Outdoor Indoor
Returnable 180-Day
Product Weight (lb.) 16.13 lb
Number of Circuits 12
Voltage (volts) 120/240
Electrical Product Type Load Center
Indoor/Outdoor2 Indoor
Number of Phases 1
Mounting Type Plug In
Phase Type 1 Phase
Number of Spaces 12
Load center width (in.) 14.25
Load center depth (in.) 3.75
Load center height (in.) 14.92
Manufacturer Warranty Square D warrants its QO branch circuit breakers to be free from defects in material and workmanship under normal care and proper usage in a residential installation, for the lifetime of the load center in which it is installed. QO brand load centers are also covered under the same lifetime warranty.
Certifications and Listings UL Listed
