VELUX
VELUX Curb Mount Tile Roof Aluminum Flashing Kit for Skylights
$202.74
Published price — same for everyone
Gone — not just here.
Substitutes below — from the same aisle.
SKU 50139412
The price on the page is the price.
Find it, price it, order it — without a phone call. Questions on spec, quantity, or freight? Contact us.
Buying more than one thing? Start your list — however you have itFreight and delivery are calculated at checkout — no surprise charges.
Details
ECW flashing can be used with tile roofs (over 3/4 in. thickness) or high-profile roofing materials with a pitch between 14 and 60 degrees
ECW 2270 flashing is designed specifically to fit VELUX curb mounted2270 models with an outside curb width of 25-1/2 in. and maximum 73-1/2 in. length
Designedto work in conjunction with a site built curb, and the ECW cannot be installed on skylights from other manufacturers, or other VELUX skylight models not noted above
Curb mounted flashing kits for shingle roofs are available (model ECL 2246)
Features
Features
| Series Name | 2270 Curb Mount Tile Roof |
| Width (Inches) | 31.5 |
| Length (Inches) | 80.5 |
| For Use with Decks | No |
| For Use with Skylights | Yes |
| For Use with Chimneys | No |
| For Use with Windows | No |
| For Use with Roofs | No |
| For Use with Doors | No |
| For Use with Vents | No |
| For Use with Pipes | No |
| For Use with Gutters | No |
| For Use with Egress Windows | No |
| Gauge | 23 |
| Color/Finish Family | Gray |
| Manufacturer Color/Finish | Neutral gray |
| Warranty | 10-year limited |
| Type | Curb mount skylight flashing kit |
| Material | Aluminum |
| CA Residents: Prop 65 Warning(s) | Yes |
| Profile | High |
| Application | Tile roof |
Third-party marks are the property of their respective owners and do not indicate sponsorship or endorsement.
