15 Amp 1 in. Single-Pole Combination AFCI Circuit Breaker - Super Arbor

Siemens

15 Amp 1 in. Single-Pole Combination AFCI Circuit Breaker

$39.13

Published price — same for everyone

Gone — not just here.

Substitutes below — from the same aisle.

SKU 495286154

The price on the page is the price.

Find it, price it, order it — without a phone call. Questions on spec, quantity, or freight? Contact us.

Buying more than one thing? Start your list — however you have it

Freight and delivery are calculated at checkout — no surprise charges.

Details

This Murray 15 Amp 1 in. Single Pole Combination AFCI Circuit Breaker trips to the center position and features LED trip indicators. This combination breaker is intended for use as a circuit breaker and AFCI device. This breaker is UL listed.
  • 1/4 in. more wiring bend space than the previous design
  • LED trip indicators
  • Both lugs at the same angle for easier wiring
  • 120 VAC and available with interrupting rating of 10kA, 22kA, or 65kA
  • Plug-In branch circuit breakers for Murray single phase load centers
  • Bolt-on branch circuit breakers for Siemens panelboards
  • Wire range: #14 - #8 AWG Cu #12 - #8 AWG Al
  • Torque rating: 25 lb. in.
  • UL listed
  • LED Trip Indicators identify the cause of the last AFCI trip
  • Protects from dangerous electrical arcing caused by damaged wire


Features
Item Weight 0.4
Voltage (volts) 120
Interruption Type CAFCI
Maximum Amperage (amps) 15
Number of Poles 1
Power Distribution Features No Additional Features
Pack Size 1
Returnable 180-Day
Mounting Type Plug-On
Breaker Type Single Pole
Electrical Product Type Breaker
Product Weight (lb.) 0.4 lb
Product Depth (in.) 1.5 in
Product Width (in.) 6.5 in
Product Height (in.) 6.5 in
Manufacturer Warranty 1 Year
Certifications and Listings UL Listed
